Arctic Freezer 8A
Охладител за процесор Arctic Freezer 8A - AM4/AM5
| Гаранция | 72 месеца |
| Тип | Въздушно |
| Сокет | AM4, AM5 |
| Височина | 136 мм |
| Обороти на вентилатора | до 2300 RPM |
| Размер на вентилатор | 100 x 25 mm |
| Конектор | 4-pin PWM |
| Подсветка | Не |
| Цвят | Черен |
Свързани продукти
- Флуидно динамичен лагер за тиха работа.
- Предварително нанесена MX-6 термопаста, улесняваща инсталацията.
- 6-годишна гаранция, подчертаваща издръжливостта на продукта.
- Опционален офсетен монтаж за AMD процесори, оптимизиращ подравняването за многодие CPU.
- Компактен дизайн, идеален за малки кутии и високи RAM модули.
- Поддържа AMD сокети AM5 и AM4, като монтажният комплект е включен само за AMD системи.
Fluid Dynamic Bearing
The low-friction sleeve bearing ensures particularly quiet operation - the fan runs pleasantly quietly both at low speeds and under varying loads.
Pre-Applied MX-6
The Freezer 8A is supplied with ARCTIC high-performance thermal paste so that the cooler can be installed and put into operation immediately.
6 Years Warranty
We are convinced of the quality and durability of our products - we are happy to pass this warranty on to our customers.
Optional Offset Mounting for AMD
Allows offset mounting of the heatsink towards the CPU hotspot, optimizing alignment for asymmetric multi-die CPUs and ensuring more efficient heat transfer.
Compact Design
Thanks to its low height, the Freezer 8A is ideal for compact cases and offers maximum compatibility with high RAM modules and nearby components.
For AMD Sockets AM5 and AM4
The scope of delivery only includes mounting material for AMD systems - this reduces packaging waste and saves unnecessary material.
Efficient Cooling with Offset Heatpipes
The offset arrangement ensures optimal heat transfer from the base to the fins – for even heat distribution and improved cooling performance.
“Efficient cooling doesn't have to be large or costly – our compact CPU cooler demonstrates how top performance can be achieved in a small form factor using a time-tested engineering principle and thorough adjustments of all parameters. Every detail counts.”
Vincent Andre, Technical Director
Specifications
| TIM | MX-6 pre-applied |
| Warranty | 6 Years |
| Operating Ambient Temperature | 0—40 °C |
| Dimensions | 83 (L) x 108 (W) x 136 (H) mm |
| Weight | 415 g |
| Packaging | Width: 131 mm Height: 110 mm Length: 171 mm Weight: 0.589 kg |
Compatibility
| AMD | AM5, AM4 |
Heatsink Specifications
| Heat Pipe | 2x Ø 6 mm Copper, Direct Touch |
| Heatsink | 46x 0.4 mm Aluminium Fins |
Fan Specifications
| General | 1x P10 PWM 100 (L) x 100 (W) x 25 (H) mm |
| Speed | 200–2300 rpm, PWM Controlled (0 rpm below 5 % PWM) |
| Bearing | Fluid Dynamic Bearing |
| Current | Voltage | 0.13 A | 12 V DC |
| Connector | 4-Pin Fan Plug |
