Arctic Freezer 36 CO
Охладител за процесор ARCTIC Freezer 36 CO - ACFRE00122A
Арт. номер: ARCTIC-FAN-ACFRE00122A
безплатна доставка
на поръчки над 50 EUR
Технически характеристики
| Гаранция | 72 месеца |
| Тип | Въздушно |
| Сокет | AM4, 1700, AM5, 1851 |
| Височина | 159 мм |
| Обороти на вентилатора | до 1800 RPM |
| Въздушен поток | до 56.3 CFM |
| Ниво на шум | до 23 dBA |
| Размер на вентилатор | 120 x 25 mm x2 |
| Конектор | 4-pin PWM |
| Подсветка | Не |
| Цвят | Черен |
Свързани продукти
Тип:
Въздушно
Сокет:
AM4, 1700, AM5, 1851
Височина:
159 мм
Обороти на вентилатора:
до 1800 RPM
Въздушен поток:
до 56.3 CFM
Тип:
Въздушно
Сокет:
AM4, 1700, AM5, 1851
Височина:
159 мм
Обороти на вентилатора:
до 1800 RPM
Въздушен поток:
до 56.3 CFM
Тип:
Въздушно
Сокет:
AM4, 1700, AM5, 1851
Височина:
159 мм
Обороти на вентилатора:
до 1800 RPM
Въздушен поток:
до 56.3 CFM
Тип:
Въздушно
Сокет:
AM4, 1700, AM5, 1851
Височина:
159 мм
Обороти на вентилатора:
до 2000 RPM
Въздушен поток:
до 56.3 CFM
Тип:
Въздушно
Сокет:
AM4, 1700, AM5, 1851
Височина:
159 мм
Обороти на вентилатора:
до 2000 RPM
Въздушен поток:
до 56.3 CFM
Тип:
Въздушно
Сокет:
AM4, AM5
Височина:
136 мм
Обороти на вентилатора:
до 2300 RPM
Тип:
Въздушно
Сокет:
AM4, AM5
Височина:
136 мм
Обороти на вентилатора:
до 2300 RPM
Тип:
Въздушно
Сокет:
1700, 1851
Височина:
136 мм
Обороти на вентилатора:
до 2300 RPM
Тип:
Въздушно
Сокет:
1700, 1851
Височина:
136 мм
Обороти на вентилатора:
до 2300 RPM
Тип:
Въздушно
Сокет:
sTRX4, TR4, sWRX8, SP3, sTR5, SP6, 4677, 4710, 4189
Височина:
145 мм
Обороти на вентилатора:
до 2300 RPM
Въздушен поток:
до 71.9 CFM
Тип:
Въздушно
Сокет:
AM4, AM5
Височина:
65 мм
Обороти на вентилатора:
до 2700 RPM
High-Class Finish with Aluminium Top Plate
With its push-pull configuration, the Freezer 36 CO not only impresses with its
efficient cooling performance, but also with its design. The soldered ends of the
heatpipes are concealed by the screwed aluminium cover, allowing it to blend
seamlessly into any PC setup and highlight both performance and appearance.
Future-Proof Compatibility
The Freezer 36 CO is multi-compatible with Intel and AMD sockets. Intel will release
the new Arrow Lake processors on the LGA1851 socket in the future. ARCTIC
customers don't need to worry that the new CPUs will also require new coolers. We
guarantee full compatibility. All Freezer 36 can be used with the new LGA1851 socket
from Intel without limitation.
Improved Fan Mounting
Thanks to the innovative mounting system, booth fans are effortlessly mounted in the
heatsink using a click system. This mounting method eliminates the need for fan clips,
making it easier to install the cooler or replace the fans, even if the cooler is already
installed. The Freezer 36 CO is therefore compatible with most 120 mm fans.
LGA1851 | LGA1700 Contact Frame
Intel's Independent Loading Mechanism (ILM) deforms the CPU by pressing it into the
socket at two points with over 40 kg. This causes pressure in the PCB, the DIE and the
solder layer between the DIE and IHS (Integrated Heat Spreader). With high thermal
load, this can lead to long-term problems. The mounting frame from ARCTIC does not
deform the CPU, reduces the mechanical load on the CPU massively, is quick and easy
to install and allows the cooler to be screwed onto the CPU's backplate. As a result,
mechanical stress on the mainboard and CPU is minimised, cooling performance
remains consistent and installation is quick and uncomplicated.
Designed for Continuous Operation
Both fans of the Freezer 36 CO are each equipped with two japanese ball bearings.
This makes these fans particularly durable and resistant to external forces such as
heat, dust and vibrations. This variant is therefore the ideal choice for 24/7 operation.
Optimised Heatsink
The fins of the heatsink are open at the side and allow the pull fan to draw additional
cool air out of the pc case through the heatsink. This side-flow design achieves even
more efficient ventilation.
P-Fans with High Static Pressure
ARCTIC relies on the proven P fans, which are known for their powerful performance.
The P series is particularly suitable for use on heat sinks and radiators. Due to the
dense fin structure of heat sinks, the fans used achieve significantly better
performance than fans designed for airflow thanks to their high static pressure.
Large Selection of Variants
The Freezer 36 is available in five different versions, all equipped with two fans in a
push-pull configuration. In addition to the standard model with aluminium heatsink
design, a version with a black heatsink is also available. For continuous operation, there
is also the CO version, which is equipped with fans with double ball bearings.
Alternatively, users can choose between a black and a white version with A-RGB fans.
Quality You Can Rely On
To ensure the longevity of our products, we carry out long-term tests under different,
sometimes very adverse conditions. In this way, we learn how we can permanently
improve our products for our customers. In addition, the excellent results of long-term
testing give us the assurance that our products are not only outstanding in terms of
quality, but also in terms of durability. This is a certainty that we are happy to pass on to
our customers, which is why we give a 6-year manufacturer's guarantee.
Specifications
Compatibillity
| Intel | LGA1851 | LGA1700 | Warranty | 6 Years |
| AMD | AM5 | AM4 | Operating Ambient Temperature | 0—40 °C |
| PI | NNPI | 250 | 234 | Dimensions | 104 (L) x 126 (W) x 159 (H) mm |
| TIM | MX-6 (0.8 g) | Weight | 890 g |
Heatsink
| Heatpipes | 4x 6 mm Ø, Copper | Fin Stack | 59x 0.4 mm, Aluminium |
Fans
| Fan | 2x P12 PWM PST CO | Current | Voltage | 0.10 A | 12 V DC |
| Speed | 200 - 1800 rpm, PWM Controlled (0 rpm below 5 % PWM) | Cable Lenght | 200 mm + 80 mm Splitter Cable |
| Bearing | Dual Ball Bearing | Connector | 4-Pin PWM-Connector + 4-Pin Plug |
