Seasonic B12-BC-650W

80PLUS®

Bronze

Cybenetics Efficiency Level

TBA

Cybenetics Noise Level

TBA

Form Factor

Intel ATX 12 V

Dimensions

140 mm (L) x 150 mm (W) x 86 mm (H)

Fan Information

Fan Size

120 mm

Fan Control

Smart and Silent Fan Control

Fan Bearing

Sleeve Bearing

Life Expectancy

25,000 hours at 40 °C, 15 % - 65 % RH

Cable Information

Modularity

Fixed cables

Cable type

Flat black cables

Electrical Features

Operating Temperature

0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)

MTBF @ 25 °C, excl. fan

100,000 hours

AC Input

Full Range

Protection

OPP, OVP, OCP, SCP

Safety and Environmental

Safety and EMC

cTUVus, TUV, CB, CCC, BSMI, CE, FCC

Environmental Compliance

Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Warranty

5 Years

AC Input

Voltage: 100 V - 240 V

Current: 10 A Max.

Frequency: 50 Hz - 60 Hz

DC Output

Rail

+3.3 V

+5 V

+12 V

-12 V

+5 VSB

Maximum Power

15 A

15 A

54 A

0.3 A

2.5 A

100 W

648 W

3.6 W

12.5 W

Total continuous power

650 W
