D-Link DGS-1016S
Суич D-Link DGS-1016S/E, 16 портов 10/100/1000, Desktop, rack mount
Арт. номер: D-LINK-DGS-1016S-E
Технически характеристики
| Гаранция | 24 месеца |
| Тип | Неуправляем суич |
| Скорост на трансфер (LAN) | 1 Gbps |
| LAN портове | 16 бр. |
| USB Порт | Не |
Свързани продукти
Тип:
Рутер
WI-FI Стандарт:
AX1500
Скорост на трансфер (Wi-Fi):
до 1501 Mbps
Скорост на трансфер (LAN):
1 Gbps
LAN портове:
4 бр.
Тип:
Управляем суич, PoE удължител
Скорост на трансфер (LAN):
1 Gbps
LAN портове:
5 бр.
Тип:
Range Extender
WI-FI Стандарт:
AC1300
LAN портове:
1 бр.
Скорост на трансфер (Wi-Fi):
до 1267 Mbps
Скорост на трансфер (LAN):
1 Gbps
Тип:
Мобилен рутер
WI-FI Стандарт:
LTE, 4G, AX300
Скорост на трансфер (Wi-Fi):
до 286.8 Mbps
Тип:
Range Extender
WI-FI Стандарт:
AC1200
LAN портове:
1 бр.
Скорост на трансфер (Wi-Fi):
до 1166 Mbps
Скорост на трансфер (LAN):
1 Gbps
Connect More, Connect Faster
The 16-Port Gigabit Unmanaged Switch is ideal for homes and small-to-medium-sized businesses looking for a quick and easy way to upgrade or expand
their network. Its slim, low- profile design means it can be placed on the desktop or mounted on the wall. Simple to set up with no software or configuration needed.
All speed and no fuss
Gigabit connectivity with support for 802.1p Quality of Service means faster uploads and
downloads without video streaming or voice calls being interrupted.
Silent and built to last
Metal casing with a fanless design not only means silent operation but also reduces
energy usage and enhances reliability.
Visual Cable Diagnostics
LEDs on each port allow you to quickly see when something is wrong with the
connection.
Good for your wallet, great for
the planet
With its integrated power-saving technologies, the switch automatically reduces power
consumption when a low-traffic or idle port is detected. It can also detect when a shorter
network cable is connected to use less power on that port.
Technical Specifications
General
| Device Interfaces | • 16 x 10/100/1000 Mbps LAN ports |
| Standards |
• IEEE 802.3 10BASE-T |
Functionality
| Switching Capacity | • 32 Gbps |
| Advanced Features | • Auto-MDI/MDIX crossover for all ports • Secure store-and-forward switching scheme • Full/half-duplex for Ethernet/Fast Ethernet speeds • Supports 9,216 byte jumbo frames • Back pressure at half-duplex operation • Wire-speed reception and transmission • Auto-negotiation for each port • Quality of Service (8 queues, strict mode) |
| Data Transfer Rates |
Ethernet: Fast Ethernet: Gigabit Ethernet: |
| Transmission Method | • Store-and-forward |
| MAC Address Table Size | • 8K entries |
| Packet Filtering/Forwarding Rates | • Ethernet: 14,880 pps per port • Fast Ethernet: 148,800 pps per port • Gigabit Ethernet: 1,488,000 pps per port |
| RAM Buffer | • 512 KB per device |
Physical
| LED Indicators | • Per port: Link/Activity/Speed • Per device: Power |
| Media Interface Exchange | • Auto-MDI/MDIX adjustment for all ports |
| Dimensions | • 280 x 110 x 25 mm |
| Weight | • 0.77 kg |
| Power Input | • 12 V / 1 A |
| Power Consumption | • Standby: 3.37 W • Maximum: 8.89 W |
| Temperature | • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -40 to 70 °C (-40 to 158 °F) |
| Humidity | • Operating: 10% to 90% non-condensing • Storage: 5% to 95% non-condensing |
| MTBF | • 564,658 hours |
| Maximum Heat Dissipation | • 30.32 BTU/h |
| Emissions (EMI) | • CE Class A • FCC Class A • ICES 003 • RCM |
| Safety | • LVD |
