Arctic P12 Silent
Вентилатор ARCTIC P12 Silent 120mm, 1045RPM, 3-Pin
| Гаранция | 72 месеца |
| Размери | 120 x 120 x 25 mm |
| Обороти | до 1050 RPM |
| Въздушен поток | до 24.1 CFM |
| Конектор | 3-pin |
| Reverse | Не |
| Цвят | Черен |
| Подсветка | Не |
Свързани продукти
Optimised for Static Pressure
During the development of the new P12 Silent, special emphasis was placed on a
focused airstream and thus a high static pressure. The fan guarantees extremely
efficient cooling, even with increased air resistance. Therefore, the P12 Silent is
particularly suitable for use on heatsinks and radiators.
High-Quality Bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the
bearing is reduced and greater efficiency is achieved. As a result, there is less heat
development as well as less bearing noise, which means you can enjoy a longer service
life from your fan.
Virtually Silent Motor
At low fan speed, the motor is the main source of unwanted noise. A motor developed
in Germany with an enhanced bearing reduces friction and noise and enables almost
silent operation.
Two Way Installation
- Push warm air out of the case
- Pull cool air into your case
Quality You Can Rely On
To ensure the longevity of our products, we carry out long-term tests under different,
sometimes very adverse conditions. In this way, we learn how to improve our products
for our customers. In addition, the excellent results of long-term testing give us the
assurance that our products are not only outstanding in terms of quality but also
durability. It's a certainty that we are happy to pass on to our customers, which is why
we give a 6-year manufacturer's guarantee on the P12 Silent.
Specifications
Performance
| Fan Speed | 1050 rpm | Static Pressure | 0.50 mmH2O |
| Airflow | 24.1 cfm | 41 m³/h | Noise Level | 0.08 Sone |
Fan
| Fan Frame | Standard | Fan Bearing | Fluid Dynamic Bearing |
| Control Type | Fixed Speed | Operating Ambient Temperature | 0-40°C |
| Connector | 3-Pin Connector | Warranty | 6 Years |
Electric Characteristics
| Typical Voltage | 12 V DC | Current | Voltage | 0.09 A | 12 V DC |
| Starting Voltage | 4.8 V | Cable Length | 400 mm |
Size & Weight
| Length | 120 mm | Height | 25 mm |
| Width | 120 mm | Weight | 139 g |
